Production Process
01
Material Cutting
02
Drilling
03
Black Hole Process
04
VCP
05
Dry Film Lamination
06
Alignment / Exposure
07
Development / Etching / Stripping
08
AOI
09
Coverlay Lamination
10
Lamination
11
Surface Treatment
12
ENIG
13
Silkscreen Printing
14
Assembly / Machine Placement
15
Lamination
16
Hole Punching
17
Electrical Testing
18
Die Cutting
19
FQC/FQA
20
SMT
21
Functional Testing
22
Dispensing
23
FQC/FQA
24
Packaging
Testing Equipment
| No. | Equipment Name | Main Inspection Items | Inspection Scope | Inspection Accuracy | Applicable Products |
| 1 | 2D Measuring Instrument | Dimensional Measurement | 450*600mm | 0.001mm | FPC，Mold |
| 2 | Tensile Tester | Base Material Peel Strength | W=1cm, 0~500KGF/CM | 0.01KGF | FPC |
| 3 | Solder Pot | Thermal Shock | 300*200mm <288°C | - | FPC |
| 4 | Salt Spray Test Chamber | Gold Surface Corrosion Resistance | 500*300mm | - | FPC |
